BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG ° |
FOIL |
|
REACTOR SML (SIDE) |
4.22 |
107 |
4.41 |
112.0 |
14.45 |
9324 |
32.0 |
FLAT |
REACTOR SML (CTR) |
4.17 |
105.8 |
4.3 |
109.1 |
13.44 |
8672 |
31.0 |
50/50 |
REACTOR MED (SIDE) |
4.33 |
110 |
4.53 |
115.0 |
15.23 |
9824 |
32.0 |
FLAT |
REACTOR MED (CTR) |
4.28 |
108.7 |
4.41 |
112.0 |
14.22 |
9172 |
31 |
50/50 |
REACTOR LRG (SIDE) |
4.44 |
112.8 |
4.65 |
117.9 |
16.00 |
10324 |
32.0 |
FLAT |
REACTOR LRG (CTR) |
4.39 |
111.4 |
4.52 |
114.8 |
14.99 |
9672 |
31.0 |
50/50 |
PERFORMER XS |
4.13 |
104.8 |
4.3 |
109.3 |
13.26 |
8554 |
33.7 |
IFT |
PERFORMER SML |
4.25 |
107.9 |
4.43 |
112.4 |
14.03 |
9054 |
33.7 |
IFT |
PERFORMER MED |
4.37 |
110.8 |
4.55 |
115.4 |
14.81 |
9554 |
33.7 |
IFT |
PERFORMER LRG |
4.48 |
113.7 |
4.67 |
118.4 |
15.58 |
10054 |
33.7 |
IFT |
PERFORMER XL |
4.59 |
116.5 |
4.78 |
121.4 |
16.36 |
10554 |
33.7 |
IFT |
ACCELERATOR GROM |
3.95 |
100.3 |
4.13 |
104.7 |
12.38 |
7895 |
33.7 |
FLAT |
ACCELERATOR MED |
4.39 |
111.5 |
4.58 |
116.3 |
15.28 |
9860 |
33.7 |
FLAT |
ACCELERATOR LRG |
4.50 |
114.3 |
4.70 |
119.2 |
16.06 |
10360 |
33.7 |
FLAT |
CARVER MED |
4.47 |
113.4 |
4.54 |
115.3 |
14.96 |
9650 |
37.0 |
FLAT |
CARVER LRG |
4.58 |
116.3 |
4.66 |
118.2 |
15.73 |
10150 |
37.0 |
FLAT |
CARVER XL |
4.69 |
119.0 |
4.77 |
121.0 |
16.51 |
10650 |
37.0 |
FLAT |
REACTOR (Q-REAR) MED |
4.03 |
102.2 |
4.40 |
111.8 |
12.63 |
8150 |
28.5 |
80/20 |
PERFORMER (Q-REAR) SML |
3.83 |
97.2 |
3.99 |
101.3 |
11.08 |
7150 |
32.4 |
80/20 |
PERFORMER (Q-REAR) MED |
4.09 |
103.7 |
4.26 |
108.1 |
12.63 |
8150 |
32.4 |
80/20 |
PERFORMER (Q-REAR) LRG |
4.33 |
110.0 |
4.51 |
114.6 |
14.18 |
9150 |
32.4 |
80/20 |
CARVER (Q-REAR) SML |
3.86 |
98.0 |
3.93 |
99.8 |
11.07 |
7140 |
33.2 |
50/50 |
CARVER (Q-REAR) MED |
4.14 |
105.0 |
4.21 |
106.9 |
12.63 |
8150 |
33.2 |
50/50 |
BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG. |
FOIL |
|
H4 SML (CTR) |
4.29 |
108.8 |
4.49 |
113.9 |
13.82 |
8917 |
37.2 |
50/50 |
H4 SML (SIDE) |
4.36 |
110.6 |
4.34 |
110.1 |
14.29 |
9221 |
38.3 |
FLAT |
H4 MED (CTR) |
4.40 |
111.7 |
4.61 |
117.0 |
14.58 |
9405 |
37.2 |
50/50 |
H4 MED (SIDE) |
4.48 |
113.6 |
4.45 |
113.0 |
15.07 |
9721 |
38.3 |
FLAT |
H4 LRG (CTR) |
4.52 |
114.6 |
4.73 |
120.0 |
15.33 |
9893 |
37.2 |
50/50 |
H4 LRG (SIDE) |
4.59 |
116.5 |
4.57 |
115.9 |
15.84 |
10221 |
38.3 |
FLAT |
H4 (Q-REAR) |
4.09 |
103.7 |
4.24 |
107.5 |
12.62 |
8140 |
33.2 |
IFT-80/20 |
BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG. |
FOIL |
|
JW GROM |
4.10 |
104.1 |
4.19 |
106.4 |
12.81 |
8264 |
35.8 |
FLAT/BEV |
JW MED |
4.46 |
113.1 |
4.56 |
115.6 |
15.13 |
9763 |
35.8 |
FLAT/BEV |
JW LRG |
4.57 |
116.0 |
4.67 |
118.6 |
15.91 |
10262 |
35.8 |
FLAT/BEV |
FT MED |
4.41 |
111.9 |
4.54 |
115.2 |
14.93 |
9634 |
34.8 |
FLAT/BEV |
FT LRG |
4.52 |
114.8 |
4.66 |
118.2 |
15.71 |
10134 |
34.8 |
FLAT/BEV |
MF GROM |
4.04 |
102.6 |
4.20 |
106.6 |
12.73 |
8215 |
36.0 |
FLAT/BEV |
MF MED |
4.35 |
110.3 |
4.50 |
114.3 |
14.62 |
9434 |
36.0 |
FLAT/BEV |
MF LRG |
4.49 |
114.0 |
4.67 |
118.5 |
15.70 |
10131 |
36.0 |
FLAT/BEV |
CM SML (SIDE) |
4.27 |
108.4 |
4.3 |
109.2 |
13.55 |
8742 |
33.8 |
FLAT |
CM SML (CTR) |
4.23 |
107.3 |
4.26 |
108 |
13.27 |
8563 |
33.8 |
50/50 |
CM MED (SIDE) |
4.42 |
112.1 |
4.45 |
112.9 |
14.49 |
9350 |
33.8 |
FLAT |
CM MED (CTR) |
4.37 |
111 |
4.4 |
111.8 |
14.19 |
9158 |
33.8 |
50/50 |
CM LRG (SIDE) |
4.56 |
115.9 |
4.6 |
116.8 |
15.5 |
9999 |
33.8 |
FLAT |
CM LRG (CTR) |
4.51 |
114.7 |
4.55 |
115.6 |
15.18 |
9795 |
33.8 |
50/50 |
KA GROM |
4.15 |
105.3 |
4.18 |
106.0 |
12.52 |
8075 |
34.9 |
FLAT |
KA SML |
4.37 |
111.0 |
4.41 |
112.0 |
13.85 |
8934 |
35.1 |
FLAT |
KA MED |
4.53 |
115.0 |
4.53 |
115.0 |
14.73 |
9500 |
35.1 |
FLAT |
KA LRG |
4.67 |
118.5 |
4.70 |
119.3 |
15.84 |
10220 |
35.1 |
FLAT |
SB SML |
4.28 |
108.6 |
4.47 |
113.4 |
14.51 |
9360 |
33.7 |
FLAT |
SF MED (SIDE) |
4.40 |
111.7 |
4.55 |
115.5 |
15.17 |
9785 |
33.3 |
FLAT |
SF MED (CTR) |
4.29 |
109.0 |
4.50 |
114.1 |
14.06 |
9070 |
31.0 |
50/50 |
BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG. |
FOIL |
|
JS MED |
4.53 |
115.0 |
4.53 |
115.0 |
15.08 |
9730 |
36.1 |
FLAT |
JS LRG |
4.61 |
117.0 |
4.65 |
118.0 |
15.81 |
10200 |
36.1 |
FLAT |
DHD MED (Ctr) |
4.30 |
109.3 |
4.46 |
113.4 |
14.25 |
9195 |
34.5 |
50/50 |
DHD MED (Side) |
4.41 |
112.0 |
4.57 |
116.0 |
15.49 |
9994 |
35.4 |
80/20 |
DHD LRG (Ctr) |
4.40 |
111.7 |
4.56 |
115.9 |
14.88 |
9601 |
34.5 |
50/50 |
DHD LRG (Side) |
4.52 |
114.6 |
4.66 |
118.3 |
16.12 |
10400 |
35.4 |
80/20 |
HS MED |
4.50 |
114.1 |
4.59 |
116.4 |
14.97 |
9656 |
31.8 |
CAMBERED |
HS LRG |
4.61 |
117.0 |
4.70 |
119.4 |
15.74 |
10158 |
31.8 |
CAMBERED |
HS (Q-Rear) |
4.14 |
105.0 |
4.21 |
106.9 |
12.63 |
8150 |
33.7 |
CAMBERED |
PYZEL MED |
4.53 |
115.0 |
4.61 |
117.0 |
15.21 |
9813 |
33.4 |
FLAT |
PYZEL LRG |
4.65 |
118.1 |
4.73 |
120.1 |
16.04 |
10350 |
33.5 |
FLAT |
PYZEL (Q-Rear) MED |
3.83 |
97.2 |
3.99 |
101.3 |
11.08 |
7150 |
32.4 |
80/20 |
PYZEL (Q-Rear) LRG |
4.09 |
103.7 |
4.26 |
108.1 |
12.63 |
8150 |
32.4 |
80/20 |
MB SML |
4.19 |
106.3 |
4.46 |
113.2 |
13.71 |
8847 |
32.0 |
FLAT |
MB MED |
4.30 |
109.2 |
4.59 |
116.4 |
14.49 |
9347 |
31.7 |
FLAT |
MB LRG |
4.41 |
111.9 |
4.74 |
120.3 |
15.26 |
9847 |
32.9 |
FLAT |
MB MED/LRG (Q-Rear) |
4.10 |
104.0 |
4.26 |
108.0 |
12.64 |
8158 |
32.4 |
50/50 |
AM XS |
4.26 |
108.1 |
4.26 |
108.0 |
13.02 |
8400 |
35.5 |
FLAT |
AM SML |
4.37 |
111.0 |
4.37 |
111.0 |
13.71 |
8846 |
35.5 |
FLAT |
AM MED (Side) |
4.57 |
116.0 |
4.53 |
115.0 |
14.89 |
9608 |
36.6 |
FLAT |
AM MED (Ctr) |
4.33 |
110.0 |
4.41 |
112.0 |
13.72 |
8852 |
35.0 |
FLAT |
AM MED (Q-Rear) |
4.10 |
104.1 |
4.26 |
108.0 |
12.64 |
8158 |
32.4 |
50/50 |
AM LRG (Side) |
4.61 |
117.1 |
4.69 |
119.0 |
15.63 |
10083 |
36.3 |
FLAT |
AM LRG (Ctr) |
4.47 |
113.5 |
4.45 |
113.0 |
14.68 |
9469 |
38.6 |
50/50 |
AM LRG (Q-Rear) |
4.10 |
104.1 |
4.26 |
108.0 |
12.64 |
8158 |
32.4 |
50/50 |
CI MED |
4.39 |
111.4 |
4.59 |
116.4 |
15.04 |
9700 |
30.3 |
FLAT |
CI LRG |
4.50 |
114.2 |
4.70 |
119.3 |
15.79 |
10190 |
30.3 |
FLAT |
CC MED |
4.39 |
111.5 |
4.58 |
116.3 |
15.28 |
9860 |
33.7 |
FLAT |
CC MED (Q-Rear) |
3.83 |
97.2 |
3.99 |
101.3 |
11.08 |
7150 |
32.4 |
80/20 |
CC LRG |
4.50 |
114.3 |
4.70 |
119.2 |
16.06 |
10360 |
33.7 |
FLAT |
CC LRG (Q-Rear) |
4.09 |
103.7 |
4.26 |
108.1 |
12.63 |
8150 |
32.4 |
80/20 |
SHARPEYE MED |
4.48 |
113.6 |
4.55 |
115.4 |
15.13 |
9761 |
34.8 |
FLAT/BEV |
SHARPEYE LRG |
4.59 |
116.5 |
4.66 |
118.3 |
15.91 |
10263 |
34.8 |
FLAT/BEV |
TOKORO MED (Ctr) |
4.43 |
112.5 |
4.44 |
112.7 |
14.25 |
9196 |
35.2 |
50/50 |
TOKORO MED (Side) |
4.50 |
114.1 |
4.50 |
114.2 |
14.65 |
9449 |
35.2 |
FLAT |
TOKORO LRG (Ctr) |
4.55 |
115.5 |
4.56 |
115.7 |
15.03 |
9696 |
35.2 |
50/50 |
TOKORO LRG (Side) |
4.61 |
117.0 |
4.62 |
117.2 |
15.42 |
9948 |
35.2 |
FLAT |
GL MED |
4.21 |
107.0 |
4.21 |
119.7 |
14.84 |
9572 |
31.1 |
FLAT |
GL (Q-Rear) |
3.77 |
95.8 |
3.74 |
95.2 |
9.38 |
6054 |
31.4 |
FLAT |
AIPA (Side) | 4.87 | 123.7 | 5.43 | 137.7 | 19.24 | 12410 | 33.6 | 50/50 |
AIPA (Ctr) | 3.33 | 84.5 | 3.13 | 79.5 | 7.91 | 5103 | 34.6 | 50/50 |
BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG. |
FOIL |
|
SPLIT QUAD (Side) |
5.41 |
137.3 |
4.79 |
121.5 |
19.27 |
12432 |
42.5 |
FLAT |
SPLIT QUAD (Q-Rear) |
4.03 |
102.2 |
4.40 |
118.8 |
12.63 |
8150 |
28.5 |
80/20 |
MB QUAD (Side) |
5.27 |
133.7 |
4.66 |
118.4 |
18.31 |
11810 |
42.5 |
FLAT |
MB QUAD (Q-Rear) |
4.03 |
102.2 |
4.40 |
111.8 |
12.63 |
8150 |
28.5 |
80/20 |
MODERN KEEL |
6.41 |
162.8 |
5.50 |
139.5 |
25.05 |
16160 |
32.8 |
FLAT |
RETRO KEEL |
7.28 |
184.8 |
4.73 |
120.0 |
22.58 |
14565 |
38.3 |
80/20 |
CI KEEL |
6.41 |
162.8 |
5.15 |
130.8 |
25.53 |
16474 |
37.0 |
FLAT |
ALBUM KEEL |
5.96 |
151.3 |
5.22 |
132.5 |
22.74 |
14672 |
38.2 |
FLAT |
PERFORMER KEEL |
6.69 |
169.9 |
5.25 |
133.3 |
26.42 |
17043 |
32.7 |
FLAT |
PERFORMER QUAD (Side) |
5.63 |
143.0 |
4.83 |
122.8 |
21.16 |
13654 |
35.7 |
FLAT |
PERFORMER QUAD (Q-Rear) |
4.11 |
104.5 |
3.12 |
79.3 |
9.65 |
6223 |
34.2 |
FLAT |
PERFORMER TWIN |
5.00 |
126.8 |
5.15 |
130.9 |
19.14 |
12350 |
33.3 |
FLAT |
PERFORMER TWIN (+1) |
3.73 |
94.8 |
3.83 |
97.2 |
11.32 |
7300 |
37.3 |
50/50 |
MR TWIN |
5.06 |
128.4 |
5.56 |
141.1 |
21.06 |
13590 |
32.1 |
FLAT |
MR TWIN (+1) |
3.31 |
84.0 |
3.34 |
84.8 |
8.23 |
5307 |
29.1 |
50/50 |
MR FREERIDE TWIN |
5.08 |
129.0 |
6.09 |
154.8 |
22.84 |
14733 |
28.4 |
FLAT |
OTIS TWIN |
5.26 |
133.6 |
5.35 |
135.8 |
21.44 |
13835 |
32.7 |
FLAT |
OTIS TWIN (+1) |
3.30 |
83.7 |
3.45 |
87.6 |
8.71 |
5620 |
32.7 |
50/50 |
ALBUM TWIN |
5.17 |
131.4 |
5.44 |
138.1 |
20.62 |
13306 |
32.8 |
FLAT |
ALBUM TWIN (+1) |
3.29 |
83.5 |
3.51 |
89.1 |
8.93 |
5759 |
29.3 |
50/50 |
BM TWIN |
5.66 |
143.7 |
5.41 |
137.4 |
23.24 |
14991 |
35.2 |
FLAT |
AM TWIN |
5.07 |
128.6 |
5.61 |
142.3 |
20.37 |
13140 |
32.1 |
FLAT |
AM TWIN (+1) |
3.45 |
87.5 |
3.69 |
93.6 |
9.46 |
6100 |
36.9 |
50/50 |
POWER TWIN |
5.26 |
133.6 |
5.35 |
135.8 |
21.44 |
13835 |
32.7 |
FLAT |
POWER TWIN (+1) |
3.30 |
83.7 |
3.45 |
87.6 |
8.71 |
5620 |
33.6 |
50/50 |
POWER TWIN S-M |
5.00 |
126.9 |
5.10 |
129.0 |
19.45 |
12546 |
32.7 |
FLAT |
POWER TWIN S-M (+1) |
3.10 |
78.6 |
3.25 |
82.4 |
7.86 |
5070 |
33.6 |
50/50 |
CHRISTENSON KEEL |
6.39 |
162.1 |
5.08 |
128.9 |
23.64 |
15250 |
34.7 |
FLAT |
CHRISTENSON TWIN |
5.14 |
130.5 |
5.22 |
132.5 |
19.75 |
12744 |
34.7 |
FLAT |
MF TWIN |
5.05 |
128.2 |
5.32 |
135.0 |
20.63 |
13308 |
37.0 |
FLAT/BEV |
MF TWIN (+1) |
3.72 |
94.5 |
3.79 |
96.1 |
10.39 |
6700 |
32.9 |
50/50 |
JS POWER TWIN | 5.26 | 133.6 | 5.35 | 135.8 | 21.44 | 13835 | 32.7 | FLAT |
JS POWER TWIN + 1 | 3.30 | 83.7 | 3.45 | 87.6 | 8.71 | 5620 | 33.6 | 50/50 |
JS MODERN KEEL | 6.41 | 162.8 | 5.50 | 139.5 | 25.05 | 16160 | 32.8 | FLAT |
NF BW G10 Tri Side | 4.34 | 110.2 | 4.58 | 116.3 | 15.25 | 9838 | 32.1 | 80/20 |
NF BW G10 Tri Ctr | 4.42 | 112.2 | 4.55 | 115.4 | 15.28 | 9855 | 33.8 | 50/50 |
NF BW Quad Side | 3.98 | 100.9 | 4.40 | 111.8 | 12.64 | 8153 | 28.9 | 70/30 |
NF BW G10 Quad Rear | 3.98 | 100.9 | 4.40 | 111.8 | 12.64 | 8153 | 28.9 | 50/50 |
BASE ” |
BASE MM |
DEPTH ” |
DEPTH MM |
AREA ” |
AREA MM |
SWEEP DEG. |
FOIL |
|
ESSENTIAL |
|
|
|
|
|
|
|
|
LB CONNECT 6” |
4.27 |
108.5 |
6.00 |
152.4 |
17.65 |
11390 |
33.7 |
50/50 |
LB CONNECT 7” |
4.99 |
126.6 |
7.01 |
177.9 |
24.05 |
15518 |
33.7 |
50/50 |
LB CONNECT 8” |
5.64 |
143.1 |
7.96 |
202.0 |
30.71 |
19812 |
33.7 |
50/50 |
LB CONNECT 9” |
6.43 |
163.1 |
9.03 |
229.2 |
39.91 |
25748 |
33.7 |
50/50 |
LB CONNECT 10” |
7.13 |
180.9 |
10.01 |
254.1 |
49.06 |
31653 |
33.7 |
50/50 |
LB FLOW II 8.5” |
6.42 |
162.9 |
8.50 |
215.7 |
30.91 |
19944 |
33.1 |
50/50 |
LB FLOW II 9.5” |
7.17 |
182.1 |
9.50 |
241.2 |
38.64 |
24928 |
33.1 |
50/50 |
LB FLOW II 10.5” |
7.96 |
202.0 |
10.54 |
267.5 |
47.53 |
30667 |
33.1 |
50/50 |
LB PIVOT II 9.75” |
7.29 |
184.9 |
9.75 |
247.7 |
52.08 |
33599 |
27.7 |
50/50 |
LB PIVOT II 10.25” |
7.66 |
194.3 |
10.25 |
260.4 |
57.49 |
37091 |
27.7 |
50/50 |
LB PIVOT II 10.75” |
8.03 |
203.9 |
10.75 |
273.1 |
63.31 |
40842 |
27.7 |
50/50 |
SIGNATURE |
|
|
|
|
|
|
|
|
LB KELIA 9.75” |
7.11 |
180.4 |
9.75 |
247.5 |
39.56 |
25523 |
33.8 |
50/50 |
LB THOMAS 9.75” |
6.85 |
173.8 |
9.76 |
247.6 |
37.29 |
24059 |
30.5 |
50/50 |
LB THOMAS 10.25” |
7.20 |
182.8 |
10.26 |
260.3 |
41.67 |
26881 |
30.5 |
50/50 |
LB THOMAS 10.75” |
7.55 |
191.7 |
10.76 |
273.0 |
45.36 |
29265 |
30.5 |
50/50 |
LB THOMAS 11.5” |
8.08 |
205.0 |
11.51 |
292.1 |
51.88 |
33471 |
30.5 |
50/50 |
LB CHRISTENSON 7.5” |
5.43 |
137.8 |
7.51 |
190.5 |
24.54 |
15833 |
33.3 |
50/50 |
LB CHRISTENSON 8” |
5.79 |
147.0 |
8.01 |
203.2 |
27.92 |
18015 |
33.3 |
50/50 |
LB CHRISTENSON 8.5” |
6.15 |
156.2 |
8.51 |
215.9 |
31.52 |
20337 |
33.3 |
50/50 |
LB CHRISTENSON 9” |
6.52 |
165.4 |
9.01 |
228.6 |
35.34 |
22800 |
33.3 |
50/50 |
LB CHRISTENSON 9.5” |
6.91 |
175.4 |
9.51 |
241.3 |
39.38 |
25404 |
33.3 |
50/50 |
LB WAXHEAD 10” |
6.82 |
173.2 |
10.01 |
254.0 |
42.60 |
27487 |
29.8 |
50/50 |
LB SKINDOG 7” |
5.32 |
135.0 |
6.98 |
177.1 |
31.69 |
16869 |
30.5 |
50/50 |
SPECIALTY |
|
|
|
|
|
|
|
|
LB CLIQUE 7” |
4.74 |
120.3 |
7.01 |
177.8 |
21.95 |
14162 |
34.5 |
50/50 |
LB CLIQUE 8” |
5.42 |
137.5 |
8.01 |
203.2 |
28.67 |
18497 |
34.5 |
50/50 |
LB CLIQUE 9” |
6.10 |
154.7 |
9.01 |
228.6 |
36.29 |
23410 |
34.5 |
50/50 |
SINGLE FIN 6” |
4.89 |
124.0 |
6.00 |
152.4 |
21.19 |
13672 |
32.7 |
50/50 |
SINGLE FIN 7” |
5.70 |
144.7 |
7.01 |
177.8 |
28.84 |
18607 |
32.7 |
50/50 |
SINGLE FIN 8” |
6.51 |
165.3 |
8.01 |
203.2 |
37.67 |
24304 |
32.7 |
50/50 |
SIDE BYTES |
|
|
|
|
|
|
|
|
CARVER SML SIDE BYTE |
3.86 |
98.0 |
3.93 |
99.8 |
11.07 |
7140 |
33.2 |
FLAT |
CONNECT SML SIDE BYTE |
3.64 |
92.3 |
3.62 |
92.0 |
9.30 |
6000 |
29.9 |
FLAT |
SKINDOG MED SIDE BYTE |
4.39 |
111.5 |
4.58 |
116.3 |
15.28 |
9860 |
33.7 |
FLAT |
HYBRID |
|
|
|
|
|
|
|
|
HARLEY SINGLE 5.5” |
4.84 |
122.8 |
5.27 |
133.7 |
18.50 |
11937 |
32.1 |
50/50 |
HARLEY XXL |
4.61 |
117.0 |
4.99 |
126.7 |
16.93 |
10923 |
34.0 |
FLAT |
HARLEY XXL (Q-REAR) |
4.10 |
104.0 |
4.26 |
108.0 |
12.64 |
8158 |
32.4 |
80/20 |
HARLEY MID |
4.45 |
112.9 |
4.70 |
119.3 |
16.03 |
10341 |
32.0 |
FLAT |
HARLEY MID (CTR) |
4.40 |
111.7 |
4.54 |
115.2 |
14.80 |
9550 |
30.7 |
50/50 |
HARLEY MID (Q-REAR) |
4.09 |
103.7 |
4.26 |
108.1 |
12.63 |
8150 |
32.4 |
80/20 |
MID SINGLE 6.5” |
4.89 |
124.1 |
6.50 |
165.1 |
22.78 |
14697 |
30.7 |
50/50 |
MID SINGLE 7” |
5.27 |
133.7 |
7.00 |
177.8 |
26.42 |
17046 |
30.7 |
50/50 |
MID SIDE BYTE |
3.43 |
87.1 |
3.62 |
92.0 |
9.28 |
5990 |
28.6 |
FLAT |
MID CARVER |
4.69 |
119.1 |
4.77 |
121.1 |
16.52 |
10657 |
37.0 |
FLAT |
MID CARVER (+1) |
4.48 |
113.7 |
4.66 |
118.4 |
15.58 |
10052 |
33.8 |
50/50 |
This page can be printed as a PDF
All FCS fins are classified by the following characteristics; Base, Depth, Area and Sweep.
Understanding how these fin characteristics can change the performance of your surfboard is an important consideration when working out which FCS fins are best for you.
BASE
Base is the length between the leading and trailing edge where the fin meets the board. Base is primarily linked to drive. Fins with a longer base will offer substantially more drive and acceleration.
DEPTH
Depth is the distance the fin penetrates into the water. Depth directly relates to hold. The greater the depth the more hold, the shorter the depth the more a board will slide and release.
SWEEP
Sweep is the angle measuring how far the outline of the fin is curved backwards; also referred to as rake. Sweep has a direct influence on pivot. Fins with more sweep produce a longer turning arc, less sweep offers a tighter turning arc.
AREA
Area is the total surface area of the fin.
DI = Discontinued item
New Sizing for Specialty Fins
You may notice new size ratings for our Specialty Fin Range. Previously, all Specialty Series fins were rated an XL. To better reflect fin sizing, we now have 3 new size categories: S-M, M-L, and L-XL.
Please refer to the Size/Fin Data to compare dimensions.
Read: The Guide To FCS Fins
Watch Video: Find Your Fin - The FCS Fin Clinic
